Dimension

13560mm*2490mm*1575mm

Loading Capacity (T)

≤ 45 T

Axle

3 axles, 13 T FUWA /Huajing Brand

Rim

9.00-22.5

Tire

12.00R22.5   12pieces

Suspension

Mechanical suspension (America Type)

Spring leaf

90(W)mm*13(Thickness)mm*10 Layer

King pin

JOST brand 3.5inch bolts type

Support leg

China brand 28Tons (Double speed)

Main beam

Height: 500mm, upper plate is 14mm, middle plate is 8mm,

Down plate is 16mm; Material is Q345B Steel.

Side wall

Height is 800mm， you can choose freely.

Brake chamber

WABCO RE 6 relay valve; T30/30 T30 Spring brake chamber（TKL brand）; One piece of 45L air tanks

ABS

Without

Twist Locks

Eight pieces (Lifting type)

Valve

WABCO valve

Light

LED light

Voltage

24V

Receptacle

7 ways (7 wire harness)

Tool box

One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)

Painting

Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint

Shipping Terms:

By bulk cargo carrier, RORO or 40HQ container.
