- Place of Origin: SHANDONG, CHINA
- Brand Name: TONGYA AUTO
- Model Number: CTY9400GGY
Products： Main Dimensions Tank Body Shape One Silo with V type Dimension 11300mm*2490mm*3990mm Tare weight 9000KGS Total Volume（m3） 45m3 Tanker Body Material 5mm / Q235 carbon steel End Plate 5mm/Q235 carbon steel Diesel Engine WEICHAI Tianhe 4100 Compressor BOHAI 10m3 Manhole Cover Cabon steel ∮500mm Discharging Valve Diameter is 4 inch Discharging Pipe 4 inch rubber hose, 1pcs, 6m/each Cat Walk With (Common model or special design) Chassis Main Beams Weldding Design ,Q345 carbon steel Axle 3 axles, 3T/FUWA/HUAJING brand Landing Gear JOST (D200T）or CHINA BRAND 28T King Pin JOST 2.00 inch bolt-in king pin Suspension Mechanical suspension America type Leaf Spring 90(W)mm*13(Thickness)mm*10 Layer Pneumatic Braking System WABCO RE 6 relay valve; T30/30 T30 Spring brake chamber; 45L air tanks. Rim 9.00-22.5 Tire 12.00R22.5 Triangle brand ABS Optional Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint Accessories One standard tool box Shipping Terms By Bulk Cargo ,RORO
- Place of Origin: SHANDONG, CHINA
- Brand Name: TONGYA AUTO
- Model Number: CTY9400GGY
