Dimension

13000×3000×1600mm (adjustable)

Loading Capacity

30T-100T

Axle

13 T/16T, FUWA /BPW /Huajing Brand

Rim

6.5-20/7.5-20/8.00-20/8.5-20

Tire

8.25R20/10.00R20/11.00R20/12.00R20

Suspension

Mechanical suspension(Germany Type or America Type)

Or Air suspension(Chinabrand or BPW brand)

Spring leaf

90(Width)mm×13(Thickness)mm×10(Layer)

or 100(Width)mm×12(Thickness)mm×12(Layer)

King pin

JOST brand 2.0 or 3.5inch bolts type or Welding type

Support leg

JOST brand C200T or China brand 28T

Main beam

Height: 450mm-520mm, upper plate thickness is 14mm-25mm, middle plate thickness is 8mm-12mm, down plate thickness is 16mm-25mm; Material is Q345 Carbon Steel.

Side beam

16mm-25mm channel steel (Material is Q235 carbon steel)

Ladder

Manual or Hydraulic type

Gooseneck

You can choose the type

Brake chamber

WABCO RE 6 relay valve; T30/30 T30 spring brake chamber; 2 pieces of 45L air tanks

ABS

Optional

Twist Locks

Four, Eight or Twelve pieces(Lifting type or Twist Screw Type)

Valve

WABCO valve

Light

LED light

Voltage

24V

Receptacle

7 ways (7 wire harness)

Tool box

One piece, 1m×0.5m×0.5m(Size can be chosen freely)(equipped with 1 unit tyre spanner, 1 unit gudgeon sleeve and 1 unit cranking bar)

Painting

Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paints.

Shipping Terms

By bulk cargo carrier, RORO or 40HQ container
